During production and inspection of components with optical data transmission, it is necessary to align fibers or fiber arrays with positioning tolerances well under 50 nm to achieve optimum connection. Multi-channel inputs and outputs also require simultaneous alignment in several axes. In each case, the high-precision F-712.MA photonics alignment system (consisting of three stacked linear axes) or F-712.HA (consisting of a parallel kinematics hexapod) integrate a nanopositioner and align several fibers in seconds.
Both systems are available for either single-sided or double-sided positioning tasks. The scope of delivery includes a high-performance digital controller (E-712), firmware routines with algorithms for very fast positioning, and an extensive software package. The matching hexapod controller (C-887) is also supplied with the parallel-kinematic setup.
Direct link for voting: https://picawards.net/vote
Well known for the high quality of its products, PI (Physik Instrumente) has been one of the leading players in the global market for precision positioning technology for many years. PI has been developing and manufacturing standard and OEM products with piezo or motor drives for 40 years. By acquiring the majority shares in ACS Motion Control, a worldwide leading developer and manufacturer of modular motion controllers for multi-axis and high-precision drive systems, PI has made a major step forward in providing complete systems for industrial applications with the highest demand on precision and dynamics. In addition to four locations in Germany, the PI Group is represented internationally by fifteen sales and service subsidiaries.
