Laser projection for efficient worker guidance in control cabinet construction
“In control cabinet construction, the process cost component can be as much as 80 percent. With a laser-based assembly assistance system, the time required for activities such as fitting and wiring can be reduced by up to 30 percent,” explains Steffen Gärtner, product manager for ASSEMBLY PRO at LAP. Based on CAD data, the laser projection system shows the exact assembly position directly on the assembly plate. This makes manual assembly more efficient: from setting the boreholes on the assembly plate to positioning the clamps and displaying the wiring information. The worker guidance software takes the user reliably through all the working steps. Additional assembly instructions can be visualized on the monitor. For quality control, the installer receives feedback about the correct execution of the assembly steps. In addition, different experience levels can be set in the worker guidance software, so that even inexperienced installers can quickly work confidently with the system.
Live at the trade fair stand: LAP demonstrates ASSEMBLY PRO in combination with CAD-PRO COMPACT laser projectors. LAP also shows the DTEC-PRO camera system for fast calibration during laser projection.
“Pick-by-laser” for assembly processes in multi-variant production
“ASSEMBLY PRO has considerable advantages, specifically for multivariant production,” explains Steffen Gärtner. These are demonstrated live by LAP at the trade fair stand, using digital ballpoint pen manufacture as an example. ASSEMBLY PRO helps installers with extracting the correct component and assembly by means of “pick-by-laser”. At the commissioning station, the CAD-PRO laser projector indicates the compartment from which the respective component should be taken and how it should be assembled. At the assembly workplace, additional assembly instructions are projected directly into the working area. Important information is available exactly where it is needed. This supports ergonomic working and enables accelerated working processes with fewer errors. As a result, companies can enhance the efficiency of manual production, even for small batch sizes and large numbers of variants.
The highlight: Visitors can individually configure and assemble their ballpoint pens themselves!
Visit LAP at MOTEK, 8. – 11. October 2018, Stuttgart, hall 6/booth 6333!
LAP is a worldwide leader in the field of laser-based systems for projection and non-contact measurements. For more than 30 years, LAP has developed, manufactured and distributed laser measuring systems, line lasers and laser projectors for industry and medicine. Numerous international industrial corporations rely on the precision technology Made in Germany for improvement of the quality of their products and the effectiveness of their production processes.
