LMI Technologies to Unveil Three New FactorySmart® 3D Inspection Products at Vision 2018 in Stuttgart

Gocator® 2500 Series Smart 3D Laser Line Profilers

Gocator 2510 and 2520 are the most advanced Gocator line profilers to date. Designed for high performance small parts inspection, these high-speed sensors generate precision 3D scans down to 8 µm X resolution.

With a custom high-speed imager, advanced optical design, dedicated FPGA processing, and built-in measurement tools for 3D alignment, part segmentation, and 3D feature extraction, Gocator 2500 sensors handle the complete processing pipeline––from raw image data to 3D result––in an all-in-one device that operates at inspection rates up to 10kHz.

Gocator® 3504 Smart 3D Snapshot Sensor

At 6 µm the Gocator 3504 is the highest XY resolution 3D snapshot sensor on the market today. Combine that with +/-0.5 µm measurement repeatability, and this groundbreaking sensor provides robust inline factory automation for sub-micron level inspection.

The 3504 has an industrial stereo camera design and point-and-shoot technology inside a ruggedized industrial package that allows for highly accurate inspection without a motion stage. The sensor is pre-calibrated and ready to measure out-of-the-box using just a web browser.

The Gocator 3504 sensor can be used in a wide range of electronics and medical applications such as connector and pin coplanarity, wire detection, surface flatness and stent inspection.

GoMax Smart Vision Accelerator

GoMax is a cost-effective hardware solution that allows users to accelerate any Gocator® 3D smart sensor in order to meet inline production speed, without the need for an industrial PC.

This plug-and-play approach connects directly to any Gocator® model and speeds up the sensor by taking over a portion of the data processing (including point cloud generation, 3D measurement, and PLC/robot communication).

“The launch of these products continues to advance our FactorySmart® approach to automated inline quality control, automation, and optimization. By offering new benchmark products in three key technology areas, LMI is serving the full spectrum of machine vision customers and working to continually meet their specific application demands,” said Terry Arden, CEO, LMI Technologies.

Visit Hall 1, Booth #1C14 at Vision 2018 (Stuttgart) to see the products for the first time.
