Industrial E-marking Switches for vehicle applications – Now available at Lantech

The switches without PoE are:

IGS-0008B
8 10/100/1000T Industrial Unmanaged Switch ; 12V models
• Dual 9V~60VDC input(12V model) compliant with ISO 7637-2
• Galvanic isolation protection (power input /Ethernet port to case ground; power input to Ethernet port)
• Relay alarm output system events
• E-marking certificate for vehicle application (12V model)

IES-0008B
8 10/100TX Industrial Ethernet Unmanaged Switch; 12V input model
• Dual 9V~60VDC input(12V model) compliant with ISO 7637-2
• Galvanic isolation protection (power input /Ethernet port to case ground; power input to Ethernet port)
• Relay alarm output for power f ail and alarm
• E-marking certificate for vehicle application (-12V model)

Galvanic isolation for dual 12V input range
The switch accepts power input 9~60VDC and is compliant with ISO 7637-2 Pulse 5a which protects switch from being damaged by high voltage that could be found at vehicle cranky start.

E-marking certificate, High reliability and extended working temperature
This switch provides ±2000V EFT and ±6000V ESD protection, which can reduce unstable situation caused by power line and Ethernet. It has high reliability and robustness coping with extensive EMI/RFI phenomenon, environmental vibration and shocks usually found in Automation, transportation, Wireless backhaul, Semi-conductor factory and assembly lines.

The -E model can be used in extreme environments with an operating temperature range of -40°C to 75°C.

The E-marking certificate makes it the most suitable switch for bus, carriage, o ther vehicles application as well as for industrial areas (-12V model)

For more information, please visit our homepage www.lantechcom.eu
