In contrast to conventional terahertz time-domain spectrometers, the TeraFlash smart does not use any mechanical delay unit, but includes two synchronized femtosecond lasers with an electronic delay (“electrically controlled optical sampling”, ECOPS). This concept results in extremely high measurement speeds: the TeraFlash smart acquires 1600 complete terahertz waveforms per second, enabling terahertz-based thickness gauging at unprecedented speed.
Flexible measurement setup
Within a measurement time of only 625 µs, the TeraFlash smart achieves a spectral bandwidth of 3 THz. The dynamic range of the pulse trace is greater than 50 dB. Within one second of averaging, this value increases to > 80 dB and the bandwidth exceeds 4 THz. Users can flexibly adjust the terahertz path length from 10 cm to 180 cm. The fiber-coupled transmitter and receiver antennas can be flexibly positioned and enable measurements in transmission or reflection.
Reflection measurements are particularly suitable to determine layer thicknesses, for example to investigate the wall thickness of plastic pipes, or the structure of polymer coatings or single- and multi-layered paint. The 10 m long fiber cables allow a spatial separation of the control unit from the measurement head, which can even be mounted on a robot arm.
For more information visit the TeraFlash smart webpage.
TOPTICA at analytica 2020: High-end Lasers for Spectroscopy, Microscopy and Quality Control
From March 31 – April 3 TOPTICA will present their latest developments in high-end laser technology at the analytica exhibition in Munich, Hall A1, booth # 301. These include Single mode diode lasers, Multi-laser engines, widely Tunable Lasers and powerful Femtosecond Fiber lasers, as well as Terahertz systems. TOPTICA’s lasers enable a variety of demanding applications in biophotonics and microscopy, materials and test & measurement.
TOPTICA has been developing and manufacturing high-end laser systems for scientific and industrial applications for 20 years. Our portfolio includes diode lasers, ultrafast fiber lasers, terahertz systems and frequency combs. The systems are used for demanding applications in biophotonics, industrial metrology and quantum technology. TOPTICA is renowned for providing the widest wavelength coverage of diode lasers on the market, providing high-power lasers even at exotic wavelengths.
TOPTICA’s employees take pride in developing customized systems. In close collaboration with several universities and institutes, latest scientific discoveries are frequently incorporated into commercial products. With a global distribution network, TOPTICA provides exceptional service worldwide. With 320 employees TOPTICA earned revenue of 74 million Euro in 2019.
