New R&S NGA100 brings linear accuracy to the basic power supply class

Rohde & Schwarz continues to expand its range of basic power supplies with the new R&S NGA100 series. The R&S NGA100 is available in four models, providing a choice of single and dual outputs with up to 35 V/6 A per output, or 100 V/2 A per output. Single output models supply up to 40 W, dual output models up to 80 W power. The dual model outputs can be combined to provide up to 200 V or 12 A.

Rohde & Schwarz has implemented a linear design throughout the output circuits of the R&S NGA100 which significantly improves performance compared to the switched-mode circuits frequently found in basic power supplies. The resulting higher accuracy means engineers can be confident of supplying exactly the right power level without any need for an additional multimeter. The standard level of readback resolution, 1 mV/100 µA, is enhanced for currents under 200 mA to a resolution of 1 µA, ideal to test low current levels typical for IoT applications in standby and sleep mode. The R&S NGA100 also has the necessary dynamic range for power and current spikes when switched to active mode.

While many basic power supplies only output maximum power within a very limited voltage/amperage range, the FlexPower technology from Rohde & Schwarz provides maximum power for a wide range of combinations, so that a single instrument can support many different applications. No matter which application, users benefit from the clear screen, intuitive user interface, and features like instantaneous statistical functions for maximum and minimum values for power, voltage and current, displayed directly on the screen.

Other features of the R&S NGA100 not commonly found in a basic power supply include logging voltage and current values for analysis, with up to 10 samples per second. For data export and remote control, Ethernet and USB are supported as standard, with optional WLAN and an external trigger with digital I/Os. Users can generate sequences of voltage/current settings at intervals down to 10 ms. The supplied power is low distortion and low noise, and cable losses can be compensated thanks to the R&S NGA100 remote sensing function. The correct level is at the input to the device under test, not at the output of the power supply.

The new R&S NGA100 power supply series is part of the R&S Essentials portfolio, and is available now from Rohde & Schwarz and selected distribution partners. For more information, visit: www.rohde-schwarz.com/product/nga100

R&S Essentials portfolio

Developers and engineers worldwide have been relying on the test and measurement expertise of Rohde & Schwarz for more than 80 years. Known for its innovative strength in performance testing solutions, Rohde & Schwarz is applying this competence with the same quality standards to its portfolio of essential bench instruments – the R&S Essentials. With the strategic goal of becoming a full portfolio supplier in the test and measurement market, the company is building this industry-defining portfolio, ranging from oscilloscopes, DC power supplies and signal generators to spectrum analyzers, vector network analyzers, meters and counters. For the R&S Essentials, Rohde & Schwarz is extending its reach through a distribution network with channel partners worldwide, offering a one-stop shop experience for any type of test and measurement task, application need and budget. Whether in the lab or field, on campus or in a production facility, the R&S Essentials demonstrate that high-quality hardware and software solutions do not have to come with a high price tag.

R&S^® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
