The Data inputs are TTL/CMOS compatible and can also be driven up to the supply voltage VDD. The ENA input can be used to place all the outputs in a high impedance state. The OPD input is used to configure the outputs as push-pull drivers or open-drain drivers, where the outputs can be returned through external loads to a maximum voltage of VDD. LS7272B-20 does not have OPD pin and its outputs are always in push-pull configuration
An internal 5V regulated supply is used to power the logic and level converter blocks. The thermal shutdown block located in the center of the IC can be disabled by setting the ENA input, Pin 12, to a voltage between 7.5V and 12V.
Upon power-up, a Power-On-Reset (POR) circuit block forces all output drivers to the high-impedance state until the power supply voltage reaches a nominal 3.9V. Included in the POR circuit block is a hysteresis of 200mV such that if the power supply drops below 3.7V all output drivers are forced to the high-impedance state until the voltage rises above 3.9V. There is a built-in 5µs delay for disabling the output drivers should the power supply drop below 3.7V. The output drivers are immediately enabled when the voltage rises above 3.9V.
Features:
- More feature-rich and cost-effective than the OL7272
- Pin for pin replaceable with the OL7272
- Push-Pull or Open-Drain output drivers
- Voltage Range: 4.5V – 30V (VDD – VSS)
- 1A peak dynamic Sink/Source output drive
- Operating frequency up to 2 MHz
- Thermal shutdown protection for output driver overload
- Enable input with Thermal Shutdown disconnect feature
- Outputs RS422A compatible
- Inputs CMOS/TTL compatible with hysteresis
- Output drivers fully connected or high-impedance state
