Rohde & Schwarz supplies Emitech’s new vehicle test center in France with its EMC test system

Emitech’s new test center is dedicated to electromagnetic compatibility tests for vehicles: two and three-wheelers, cars, trucks, tractors, construction machinery, etc. The reinforcement of a heavy load area supporting up to 40 t allows it to accommodate construction machinery as well as high-tonnage and high-volume equipment found in the defense, aeronautics, railways and nuclear power sectors and, by extension, industry. The center also has the largest and most recent Faraday cage built in France, which is used to perform electromagnetic compatibility tests to ensure that the equipment under test does not generate interference and is not itself disturbed by interference representative of the context in which it will be used.

The R&S BBA and R&S BBL amplifiers support the EMC tests at Emitech’s test center. They are housed in several system racks and supply high-power RF signals to all transducers used in the conducted and radiated EMC test setups. More specifically, two racks for R&S BBL200 amplifiers and a 3 kW power class R&S BBA150 amplifier are installed below the chamber, which work together to create a high field strength from 9 kHz to 1 GHz. The amplifiers use one stripline antenna and two log-periodic antennas. Additionally, a mobile rack including 600 W/300 W power class R&S BBA130 amplifiers with one horn antenna is used inside the chamber for high field strength tests up to 6 GHz.

The R&S BBA amplifiers cover frequency bands up to 6 GHz. These amplifiers can be used for a variety of applications, including the various standards for EMS measurements. The R&S BBL200 liquid-cooled power amplifiers for high field strengths complement the test setup. These amplifiers are ideal for applications requiring high RF power in a frequency range from 9 kHz to 250 MHz. They are liquid-cooled, solid-state, highly rugged, quiet and efficient. Precise monitoring of all runtime parameters ensures maximum robustness and reliability. The amplifiers are designed for continuous operation and deliver constant power even under mismatch conditions.

This Rohde & Schwarz project for the French automotive market represents another benchmark EMC test solution.

Automotive test solutions – Test it. Trust it.
As a leading worldwide provider of test and measurement software, instruments and systems, Rohde & Schwarz employs its technical expertise to develop innovative solutions for the entire automotive lifecycle from predevelopment to production. OEMs, tier 1s, chip suppliers and engineering service providers around the world rely on the company’s proven test solutions for automotive radar, connectivity, infotainment, high-performance computing and EMC compliance. With innovative solutions for radar tests in development, integration production, Rohde & Schwarz supports its customers as a reliable partner for the launch of next-generation ADAS and AD systems. The company’s many years of experience and expertise in wireless communications ensure robust connectivity conforming to all standards from 5G and C-V2X to UWB, Wi-Fi and GNSS. Rohde & Schwarz instruments enable the development and debugging of in-vehicle networks with leading-edge bus speeds as well as ECUs such as high-performance domain controllers, and help to eliminate EMC issues. Rohde & Schwarz also offers T&M equipment and custom turnkey test systems for carrying out EMI and EMS measurements on vehicles and vehicle components in line with all major CISPR, ISO and manufacturer-specific EMC standards. These systems and equipment support full vehicle antenna testing and wireless coexistence testing with the user’s own systems and instruments. The company also offers outstanding solutions at the component and board level tests during ECU production. Partners and customers around the world use these test solutions to ensure automotive components and systems function correctly, interact flawlessly and smoothly and communicate faultlessly with the outside world.

Groupe Emitech
Emitech was founded in 1989 and, with its subsidiaries Eurocem, Adetests, Environne’Tech, Pieme, Lefae, EMC, EEA and R&D Moteurs, forms the Emitech Group. Emitech’s headquarters are located in Montigny-le-Bretonneux (78). The Group has 18 sites with test centers dedicated to the design and validation of current and future mobility solutions as well as for the qualification, CE marking and market launches of products of all kinds.
The Group’s areas of expertise are diverse and complementary: EMC, radio, electrical safety, mechanical, vibratory, acoustic, NVH, shock, thermal, physical-chemical, fire, hydraulic environments, etc., as well as mechatronics, software and pollution.
The core business of the Emitech Group is test control, but it also extends to other fields such as the design of test benches, engineering, training and metrology.
The Emitech Group has 600 employees and is expected to generate EUR 58 million in 2022.
