First Endovascular Navigation1 with image fusion technology integrated into a mobile C-arm
Ziehm Imaging’s hybrid solution based on the Ziehm Vision RFD Hybrid Edition2 has been established successfully in the market for years. For the first time, the function of fusion imaging is integrated into the C-arm, eliminating the need for a separate device. This allows greater ease of use and saves valuable space in the operating room as imaging and intraoperative vascular navigation is now combined into one single user interface.
Greater Precision and Reduced Radiation Exposure
Intraoperative Endovascular Navigation enables physicians to achieve greater precision in demanding hybrid interventions. The combination of preoperative CT data and intraoperative fluoroscopic images provides even more accurate results while reducing radiation dose and contrast agent use. Using artificial intelligence-based algorithms, vascular image fusion is automated and acts fast.
The Endovascular Navigation software is designed for interventions in the aorto-iliac region. It can be used for EVARs as well as for complex interventions such as FEVARs.
Prof. Dr. med. Johannes Kalder from University Hospital of Giessen and Marburg reports:
“We are very proud to be the first in the world to use this groundbreaking new technology on a mobile C-arm. Endovascular navigation allows us to bring planning and fusion imaging to the C-arm and work directly from the sterile field as we are used to. Image quality and workflow improvements are almost equivalent to those of fixed installed systems. We are particularly impressed by the automatic re-registration after changing the position of the C-arm. The savings in procedure time and expected reduction in contrast agent and radiation dose make a real difference for us and our patients in the further course of care.”
A complete new imaging system for Ziehm Imaging’s premium portfolio
On the joint booth with its daughter companies Orthoscan and Therenva, Ziehm Imaging will be presenting further solutions in the field of mobile imaging. All Ziehm Imaging C-arms showcased onsite are part of the premium portfolio CMOSline3 that is elevated with QuantumStream – a completely new imaging system.
The premium portfolio comes with up to 30 kW generator (according to IEC 60601-2-54), the 100 µm pixel size CMOS detector and the first 2k2k image processing. It also features a 4K UHD monitor.
- With its all-in-one design, the Ziehm Solo FD is one of the most compact C-arms on the market. This product line does not require a separate monitor cart, making it easy to maneuver even in the smallest treatment scenarios.
- Ziehm Vision RFD 3D covers a wide range of applications, from high-end orthopedics, traumatology and spinal surgery to innovative vascular procedures.
These innovations emphasize Ziehm Imaging’s commitment to advancing mobile imaging technology.
The Orthoscan TAU 2020, a mini C-arm for hand and foot surgery, completes the portfolio. It has the largest detector available for a mini C-arm and a 32” 4K resolution diagnostic touchscreen monitor for exceptional viewing.
ECR 2025 | February 26 to March 1 | Austria Center Vienna, Bruno-Kreisky-Platz 1, Vienna, EXPO X2.
Visit Ziehm Imaging, Orthoscan and Therenva at booth #224.
You can find further information at: www.ziehm.com / www.therenva.com / www.orthoscan.com
1 Endovascular Navigation represents an optional medical device software package owned by Therenva SAS. Planning is performed with the software EndoSize, also owned by Therenva SAS. The EndoSize license is included in the Endovascular Navigation software package. More information: www.ziehm.com
2 Ziehm Vision RFD Hybrid Edition represents a group of optional hardware and software that creates an option package on the device named Ziehm Vision RFD.
3 The CMOSline is a system configuration based on the Ziehm Imaging CMOS flat-panel detector.
About Ziehm Imaging
Founded in 1972, Ziehm Imaging stands for the development, manufacturing and worldwide marketing of premium mobile intraoperative imaging solutions.
With more than 900 employees around the globe, the company is the acknowledged innovation leader for mobile C-arms and the market leader in Germany and many other European countries.
Ziehm Imaging covers the broadest spectrum of clinical applications and services with its full-size C-arm portfolio.
Together with its daughter company Therenva, Ziehm Imaging sets standards standards with innovative solutions. This enables specialists to plan, track and navigate in the cardiovascular, endovascular and neurovascular field.
With its Global Headquarters in Nuremberg, Germany and subsidiaries in the US and many countries Ziehm Imaging has received several awards for its cutting-edge and patient-centered achievements, including various Frost & Sullivan and iF Design awards.
About Therenva
Since 2007, Therenva has been providing innovative and reliable medical software tools to help physicians and healthcare professionals prepare and perform efficient cardiovascular procedures.
From case planning with accurate measurements to intra-operative image fusion guidance, EndoSize and EndoNaut assist cardio-vascular interventions with greater precision and efficiency, thanks to their highly performing AI and deep learning-based algorithms and to an always user-friendly workflow.
About Orthoscan
Since 2002 Orthoscan has been the global leader in mini C-arm imaging committed to innovative imaging solutions for orthopedic surgeons in surgical and clinical environments, designed for extremity imaging capable of producing digital x-ray and fluoroscopic images. Orthoscan’s TAU family of mini C-arms are the first mini C-arms designed and approved for use with pediatric patients. Each TAU product includes Intelligent Dose Reduction that allow the systems to achieve significant dose savings at every level without sacrificing image quality.
